8.8 GeoGebra Illustrative Mathematics - Pythagorean Theorem and Irrational Numbers

This unit introduces students to irrational numbers with a focus on connecting geometric and algebraic representations of square roots, cube roots, and the Pythagorean Theorem.

In the first section, students extend work from grade 6, composing and decomposing shapes to find the areas of tilted squares. They see “square root of ” and  to mean the side length of a square with area  square units, and understand that finding the solution to equations of the form  means determining which values of  make the equation true. Students learn and use definitions for “rational number” and “irrational number,” learn (without proof) that  is irrational, and plot square roots on the number line.

Three right triangles are indicated. A square is drawn using each side of the triangles. The triangle on the left has the square labels “a squared equals 16” and “b squared equals 9” attached to each of the legs. The square labeled “c squared equals 25” is attached to the hypotenuse. The triangle in the middle has the square labels “a squared equals 16” and “b squared equals 1” attached to each of the legs. The square labeled “c squared equals 17” is attached to the hypotenuse. The triangle on the right has the square labels “a squared equals 9” and “b squared equals 9” attached to each of the legs. The square labeled “c squared equals 18” is attached to the hypotenuse.

In the second section, students continue using tilted squares as they investigate relationships between side lengths of right and non-right triangles. Students are encouraged to notice patterns among the triangles before being shown geometric and algebraic proofs of the Pythagorean Theorem. They use the Pythagorean Theorem and its converse to solve problems in two and three dimensions, for example, to determine lengths of diagonals of rectangles and right rectangular prisms, and to estimate distances between points in the coordinate plane.

In the third section, students see that “cube root of " and  mean the side length of a cube with volume  cubic units. They also represent a cube root as a decimal approximation and as a point on the number line.

In the fourth section, students consider the decimal expansions of rational and irrational numbers. They learn how to rewrite fractions as a repeating decimal, how to rewrite a repeating decimal as a fraction, and reinforce their understanding that irrational numbers have a place on the number line even if they cannot be written as a fraction of integers.
